FIG. 1
8. PREPARING THE VACUUM CLEANER
8.1 ATTACH THE CASTORS - FIG. 1
Warning! Do not make any of the following adjustments
with the vacuum cleaner connected to the power
supply.
With the Power head taken off turn the container upside
down, slot the four castors in position.
FIG. 2
8.2 ATTACH THE HOSE - FIG. 2
Insert the large end of the hose into the vacuum
port and lock it by pushing and twisting as shown
will lock it in position.
FIG. 3
8.3 DRAIN PLUG - FIG. 3
Insure that the drain plug is fitted in position before
using the vacuum cleaner for any operation.
NOTE: Now the vacuum cleaner is assembled, you
need to decide what function the vacuum cleaner is to
be used for, either Dry / Wet vacuuming or Blowing
and amend filters as instructed in the further sections of
this manual.
10
