9. SETTING THE VACUUM CLEANER
FIG. 4
FIG. 6
DRY VACUUMING
9.1 FITTING CLOTH FILTER - FIG 4
Warning! Do not make any of the following adjustments
with the vacuum cleaner connected to the power
supply.
NOTE: Insure that the tank and all accessories are dry if
used previously for wet vacuuming.
Slide the cloth filter over the float cage, insure that
it completely covers down to the base.
9.2 FITTING PAPER DUST BAG - FIG 5
Fix the paper dust bag to the inner side of the hose
connector in the tank as shown. When using the paper
dust bag, dirt can be removed more hygienically.
Note: As suction power decreases, replace the paper
dust bag with a new one.
9.3 ATTACH ACCESSORIES - FIG. 6
Replace top, push down to engage the clasps.
Choose which combination of accessories is need to be
used for the job.
FIG. 5
11
