- 4 -
GETTING TO KNOW YOUR MULTIMETER
(1) Function Selector.
(2) Power Switch.
(3) L.C.D. Screen.
(4) Probes.
(5) V, , mA (Voltage, Resistance, Amperage)
Jack Socket.
(6) Common Earth Jack Socket.
- UNPACKING: After removing the packing material, make sure the product is in perfect
condition and that there are no visible damaged parts. If in doubt, do not use the digital
multimeter and contact the dealer from whom it was purchased.
The packaging materials (plastic bags, polystyrene, etc.), must be disposed of in an
appropriate refuse collection container. These materials must not be left within the reach of
children as they are potential sources of danger.
(4)
(3)
(6)
(5)
(1)
(2)
