TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE 20KÙ
MAXIMUM INPUT LEVEL +17dB
OUTPUT IMPEDANCE 50Ù (bal) 100Ù (unbal)
MAXIMUM OUTPUT LEVEL +17dB
BANDWIDTH 23Hz to 31KHz -1dB
NOISE AT UNITY GAIN ref 0dB, GATE open
Wideband 22Hz - 22KHz CCIR ARM IEC A Q-Pk CCIR
AV -90dB -95dB -95dB -97dB -84dB
RMS -88dB -93dB -93dB -95dB
DISTORTION
100Hz 1KHz 10KHz
0dB input < 0.025% < 0.025% <0.025%
POWER REQUIREMENTS 93-125Volt or 185-250Volt at 50-60Hz, 9 Watts
FUSE RATING 32mA for 230Volt, 63mA for 115Volt
FUSE TYPE 20mm x 5mm, Class 3 Time delay, 250 Volt working.
CONFORMING TO IEC127-2
CASE SIZE 482mm (w) x 44mm (h) x 200mm (d)
WEIGHT (incl packaging) 3.4 Kgs
-13-
