MX30 OPERATORS’ MANUAL 11
TECHNICAL SPECIFICATIONS
(Measurements taken using +4dBu balanced XLR input where applicable)
INPUT IMPEDANCE 20KOhm (bal), 4KOhm (unbal)
MAXIMUM INPUT LEVEL +21dBu
OUTPUT IMPEDANCE 50 Ohm (bal), 100 Ohm (unbal)
MAXIMUM OUTPUT LEVEL +20dBu
BANDWIDTH <10Hz to 36KHz -1dB
CROSSTALK @ 10KHz ! 94dB
@ 1KHz <100dB
NOISE AT UNITY GAIN with Gate OFF
Wideband 22Hz - 22KHz CCIR ARM IEC A Q-Pk CCIR
AV ! 95dB ! 101dB ! 100dB ! 102dB ! 89dB
RMS ! 95dB ! 101dB ! 98dB ! 100dB ! 87dB
DISTORTION
Typical Input 100Hz 1KHz 10KHz
Unity Gain, +4dBu input < 0.03% < 0.02% <0.03%
+14dBu input, 10dB Gain Red. < 0.2% < 0.2% < 0.2%
POWER REQUIREMENTS 115Volt or 230Volt at 50-60Hz, 9 Watts
FUSE RATING T32mA for 230Volt, T63mA for 115Volt
CONFORMING TO IEC 127-2
FUSE TYPE 20mm x 5mm, Class 3 Slo-Blo, 250Volt working
CASE SIZE 482mm (w) x 44mm (h) x 200mm (d)
WEIGHT (incl packaging) 3.2 Kgs
