Configuring Web Pages
The Quick Start Wizard is designed for you to easily set up your modem for
Internet access. You can directly access the Quick Start Wizard via Web User
Interface.
1. Make sure your PC connects to the modem correctly.
Notice: You may either simply set up your computer to get IP
dynamically from the modem or set up the IP address of the computer
to be the same subnet as the default IP address of Vigor modem
192.168.1.1.
2. Open a web browser on your PC and type http://192.168.1.1. A pop-up
window will open to ask for username and password. Please type
“admin/admin” as the username and password. Then click Login.
Notice: If you fail to access to the web configuration, please go to
“Trouble Shooting” for detecting and solving your problem.
3. Now, the Main Screen will pop up. Click Quick Start Wizard.

Draytek Vigor 130 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	-
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Mobile network generation	Not supported
Ethernet LAN (RJ-45) ports	1
Product color	White
Power source type	DC
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	125 mm
Width	182 mm
Height	40 mm
Weight	240 g
