Vigor160 Series User’s Guide
29
With the IP address(es) pinging, Vigor router can check if
the WAN connection is on or off.
TTL (Time to Live) – Set TTL value of PING operation.
MTU It means Max Transmit Unit for packet.
RIP Protocol
Routing Information Protocol is abbreviated as RIP（RFC1058）
specifying how modems exchange routing tables information.
Click Enable RIP for activating this function.
Bridge Mode Enable Bridge Mode - If the function is enabled, the router
will work as a bridge modem.
Enable Full Bridge Mode – If the function is enabled, the
router will work as a bridge modem which is able to forward
incoming packets with VLAN tags.
WAN IP Network Settings This group allows you to obtain an IP address automatically
and allows you type in IP address manually.
Obtain an IP address automatically – Click this button to
obtain the IP address automatically.
Router Name – Type in the modem name provided by ISP.
Domain Name – Type in the domain name that you have
assigned.
DHCP Client Identifier This feature is offered for certain ISP with special request.
Check this box to enable the function of DHCP client
identifier for some ISP.
Username – Type a username used for such function.
Password – Type a password used for such function.
Specify an IP address Click this radio button to specify some data.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 8 public IP addresses other
than the current one you are using. Notice that this setting is
available for WAN1 only. Type the additional WAN IP address
and check the Enable box. Then click OK to exit the dialog.
IP Address – Type in the private IP address.
