Enter the username and password provided to you by your Internet Service Provider. Username should be in the
form of an email address, and the password will need to be entered into both the Password and Confirm Password
fields. All fields are case sensitive.
In the ADSL section (you may need to click on ADSL to expand this) enter the following settings depending on
whether you have an ADSL or VDSL connection, then click Finish.
Configure VID Tag (VDSL only)
On the navigation menu, click Network and then WAN. Select the DSL tab and tick the checkbox of the profile
named "[DSL] PVC1". Click the Edit button.
Locate the VLAN Encapsulation option and enable it. The VLAN ID box will appear, enter 10 and click Apply.
