14
(3) Assemble the SIM1 and SIM2 with the card cassette. Later insert the cassette
into the SIM card slot and the direction of card notch must be on the left side.
W
W
a
a
r
r
n
n
i
i
n
n
g
g
There are two types of antennas provided for Vigor2865Lac, which must be
installed in different locations carefully and correctly. Wrong installation might
cause bad signal of wireless connection. Therefore, pay attention to the
installation of antennas by referring to the following illustration.
SMA jack for
WLAN
Antenna
SMA jack for LTE Antenna
(with extension base)
To Next Page
