3
On (Blue) The device is connected with 10Gbps.
On
(Amber)
The device is connected with 10/100Mbps.
Blinking The system is sending or receiving data
through the port.
(SFP+)
Off The port is disconnected or the link is failed.
Interface Description
Port 1 ~ 24 (GbE RJ45)
Port 1 ~ 24 (PoE, for P2280x)
Port 1 to Port 24 can be used for Ethernet
connection and PoE connection, depending on
the device connected.
Port 25 ~ 28 (SFP+)
Port 25 to Port 28 are used for fiber
connection.
Console
Used to perform telnet command control.
Power inlet for AC input (100~240V/AC,
50/60Hz).
Note
The following limitation is suitable for VigorSwitch P2280x
Power Output --
IEEE 802.3af Max. 15.4W Output Supported
IEEE 802.3at Max. 30W Output Supported
PoE Power Budget –-
400 Watts (Max)
