Room thermostats
Make Model
Drayton RTS 1 & 2 N L 3
Drayton RTS 4, 5, 6, 9 & 10
N
L 132
Drayton Digistat 1 1 3 2
ACL Lifestyle PT271/371 N L 1 3 2
ACL Lifestyle TS 142 E 4 1 2
ACL Lifestyle TA 350 5 1 3 2
Drayton Digistat (old version) 4 1 2 3
Drayton RT & RTE 4 1 2 3
Danfoss Randall TP1 E N L 1 2
Danfoss Randall RT1. TP2, 3, 4 & 5 1 3 2
Danfoss Randall RD3, RD3A 4 1 2
Danfoss Randall RTC, RTM, RSR E N 3 1 2
Danfoss Randall R504 N 3 1 2
Honeywell 6060, 6061, 6063 2 1 3 4
Honeywell CT200 A B C
Horstman HRT 1 E 4 1 2
Landis & Gyr RAD 1 E 1 2 3
Potterton PRT 1 N L H
Potterton PRT 2 & 100 ST N TL H
Potterton PRT 100 DT N TL H C
Sunvic TLX 2259 E N L 1 2
Sunvic TLX 2356 E 3 1 2
Sopac TA 350 E 1 3 2
Sopac TA 351 E 4 1 3 2
Switchmaster SRT 2 5 1 3 2
Tower SS E 4 1 2
Earth
Neutral
Live
Common
Demand
Satisfied
Wiring (schematic)
Note: It is essential to make a neutral connection to terminal N.
Note: Link between terminals L and 1 if mains voltage is
required on the thermostat switch.
Information
The RTS room thermostat replaces earlier models of both
ACL and Drayton room thermostats subject to a maximum
load of 2(1)A 230V ac. The wiring conversion between
these models is:
ACL ACL Drayton RTS RTS
TS142 TA350 Roomstat 1,2 4, 6,
RT (E) & 3 9 & 10
Live supply 1 – 1 L L
Neutral
4– 4NN
(accelerator heater)
Call for heat 2 3 2 3 3
Heating satisfied
–2 3 –2
(call for cooling)
Volt free
–1 – –1
switch common
Earth connection E 5 – – –
Conforms to the essential requirements of the following
directives:
89/336/EEC – Electromagnetic compatibility
73/23/EEC – Low voltage directive
N L 1 2 3
N
230V AC 50HZ
fused 3A
L
Call for
heat
RTS1, RTS2 and RTS3
N L 1 2 3
N
230V AC 50HZ
fused 3A
L
Call for
heat
RTS4, RTS6, RTS9 and RTS10
COM
Heating satisfied o
