Bethany Ottoman Bed - Assembly guide - Page 10
5a
6a
Slat Frame Support Bar
e
x4
b
x4 c
x4
d
x1
e
c
d
b
h
j
J
h
x2
j
x1
WAR
NING! HAZARD DO NOT REACH INTOTHE SPACEB
ELOW!
Make certain the bed is squared up as
shown in the diagram then tighten ALL
the bed assembly bolts 100%.
Fit the side rail cross bar (J).
Loosely fit the piston stems to the upper axles.
Please make sure the cylinder
(largest diameter) is at the top.
Fit the piston stems to upper axles
using lock nuts (h)
Do not tighten these nuts 100%. yet
PLEASE CARRY ON THE ASSEMBLY FOR BETHANY, FROM STEP (7)
