Chloe Ottoman Bed - Assembly guide - Page
12
0
cm
1 2 3 4 5 6 7 8 9 1100 11 12 13 14 15 16 17 18
Spring Washer for M8 bolt
a
Flat Washer for M8 bolt
Spring Washer for M8 bolt Flat Washer for M8 bolt
b c d x1
h x4
i x6
j x1
Allen Key for M8 bolt
Flanged lock-nuts M8
for gas-lift pistons
Nut for M8 bolts
Spanner for M8 nut
Bolts (M8x25mm)
Fitting side rails (C&D) to
headboard & footboard (A&B)
b c
e x4
Bolts (M8x50mm)
Fitting cross bar (J) to side
rails (C&D)
Cross head screwdriverTape measure
Tools required
m x5
b x5 c x5
Bolts (M8x25mm) for fitting
ottoman support bar system
Flat washer for M8 bolts
O x1
Q x1
P x1
Spring washer for M8 bolts
Hardware needed for fixing ottoman support bar (O.S.B) to the solid mattress base boards
Packed in the side rail carton, inside Pack 2 - hardware pack ( C
)
Ottoman Support Bar
Fixed retaining bracket
- side rail
Parking bracket - slat frame
Double & King x22
Super King x24
Double & King x26
Super King x28
Double & King x26
Super King x28
k x1
Tube Spanner for M8 nut
Bolts (M6x45mm) for fitting
plinths (E) to side rails (C&D)
and (R) to footboard (B)
r x1
Allen Key for M6 bolt
Dowel (Ø6x40mm)
p
n x4
q
f x6
e
Bolts (M8x50mm)
Fitting connection bars (W) to
mattress base boards (T&U)
Double & King x8
Super King x16
Threaded stud (M8x50mm)
Fittings for Chloe
Please check you have all the parts listed below with your product:
Hardware needed for fixing side rails to headboard & footboard
Packed in side rail carton, inside Pack 2 - hardware pack (A)
Hardware needed for fixing plinths to side rails & footboard
Packed in side rail carton, inside Pack 2 - hardware pack (D)
Hardware needed for fixing solid mattress base board
Packed in ottoman carton, inside Pack 3B - hardware pack (B)
a
Double & King x10
Super King x6
Bolts (M8x25mm)
Fitting mattress stoppers (M)
and metal connection plates (X)
to mattress base boards (T&U)
x9
x9
Double & King x24
Super King x28
Flat Washer (M6x13mm)
for M6 bolt
Double & King x18
Super King x22
To Next Page
