Bed Frame Assembly
8
9
x 4
Ø10 x 40mm
Wood Dowel
F
x 2
7 x 100mm Screw
C
x 2
Ø6.3 x 40mm Bolt
E
F
F
C
E
09
09
Bolt hole
E
E
Loosely tighten the Bolts
