Parts
Important information
The bed you have purchased comes complete with everything needed to build your bed in one box so please
follow the instructions below in the current order. Before you begin assembling your bed, please take a moment
to read through the instructions and make sure that you've got all the relevant parts listed on the following pages.
Marley Bed Frame - Assembly guide - Page 3
1
1
2 Pr
4
A. Headboard
B. Footboard
C&D. Side Rails
E. Side Rail Slat Support Bars
F. Legs 4
1
3
28
G. Cross Bar
H.
Cross Bar Support Legs
I. Wooden Slats
J. Single Plastic Caps 28
K.
Double Plastic Caps
2
L. Centre Support Bars 2
M. 14
L Metal BracketN. 2
Parts list
Metal Connection Plate
C
D
