DREAMS Mid Sleeper - Product Components and Fittings; Parts Checklist; Fittings Checklist

15
Page 2 of 11
Do not discard any of the
packaging until you have
checked that you have all the
parts and the pack of fixings.
Fittings Checklist
Parts Checklist
Ø6.3 x 100mm Bolt
x 28
x 8
Ø10 x 40mm Wood Dowel
Ø6.3 x 30mm Bolt
Check size of fixings against this guage (dimensions in mm)
1 0
2 0 3 0 4 0 5 0 6 0 7 0 8 0 9 0 10 0 11 0
x 22
x 30
x 9
A
M4 Allen Key
x 1
G
D
B
C
F
7 x 100mm Screw
4 x 40mm Screw
Half Round Nut
x 8
E
Top Rail x2pcs
Upper Headboard x2pcs
Leg x2pcs 3a=1pc, 3b=1pc
Leg
Leg
Leg
Long Guardrail x2pcs
Short Guardrail x2pcs
Upper Back Side Rail
Upper Front Side Rail
Guardrail Support x3pcs
Long Bar
Complete Twin Slat x1set
Ladder Step x3pcs
01
02
03
04
05
06
07
08
09
10
x 6
I
Ø7 x 80mm Bolt
Ø6.3 x 40mm Bolt
x 6
H
11
12
14
Short Bar x2pcs
13
01
01
02
02
03
04
05
06
07
07
08
08
09
10
11
11
11
12
13
14
14
14
15
15
03
b
a
