Dremel 100 - EZ Drum Operating Instructions; Loading and Removing EZ Drum Sanding Bands

23
EZ Drum™ Mandrel No. EZ407SA has a
spring loaded sleeve and is used with
sanding bands.
A
lways make sure the
rotary tool is “OFF” and
disconnect the plug from the power
source or the battery pack from the tool
before changing accessories. Such
preventative safety measures reduce the risk
of starting the power tool accidentally.
Always make sure accessory is properly
seated on mandrel before use. Incorrect
seating of accessory on mandrel may lead to
personal injury or property damage.
To load accessory:
1. As indicated, place two fingers underneath
the mandrel and pull firmly up. This will
place the EZ Drum™ in the "unlocked"
position (Fig. 1).
2. Keeping two fingers beneath the mandrel,
slide the sanding band down until the
entire blue mandrel is covered (Fig. 2).
3. To return to "locked" position, press firmly
down on the top of the mandrel (Fig. 3).
Removing the sanding band on
the mandrel:
1. Place two fingers underneath the mandrel
and pull firmly up. This will place the EZ
Drum™ in the "unlocked" position (Fig. 1).
2. Sanding band will now easily slide off
mandrel (Fig. 2). Do not squeeze sanding
band when removing from EZ Drum™
mandrel, this can lead to rubber band
pulling off mandrel and becoming
inoperable.
FIG. 1
FIG. 2
FIG. 3
EZ Drum
™
Operating Instructions
