-6-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories
. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
NOTE: For tool specifications refer to the nameplate on your tool.
FIG. 1
Model 6300 Multi-Max Oscillating Power Tool
VARIABLE SPEED
CONTROL DIAL
ON/OFF
SWITCH
POWER
CORD
VENTILATION
OPENINGS
ACCESSORY
CLAMPING
SCREW
ACCESSORY HOLDER
Model number 6300
No load speed n
0
10,000-21,000/min
Voltage rating
120 V 60 Hz
BLADE
WASHER
