11
CHARGER
BATTERY
PACK
RELEASE TAB
RELEASE TAB
BATTERY
PACK
COLLET NUT
SWITCH
Functional Description & Specifications
Disconnect battery pack from tool or place the switch in the locked or off position before
making any assembly, adjustments or changing accessories. Such preventive safety mea-
sures reduce the risk of starting the tool accidentally.
!
WARNING
Model 7300 Cordless Rotary Tool
Model number 7300
Voltage rating 4.8V
No load speed n
0
6,500-13,000/min
Collet capacities1/32, 1/16", 3/32", 1/8"
Charger 756-01
Charge Time 3 Hour
Voltage rating 120 V 60 Hz
Battery pack 755-01
Capacity 200 mA
DM 2610011275 05-10:DM 2610011275 05-10 5/6/10 10:38 AM Page 11
