SKU 67025 For technical questions, please call 1-800-444-3353. Page 10
Part Description Q’ty
1 Chuck 1
2 1
3 Tapping screw 3
4 Clamp plate 1
5 Spring 3
6 Impact bracket 1
7 Impact Ring Selector 1
8 Shaft 1
9 Small washer 1
10 Ball Ø2 12
11 Wall shaft sleeve 1
12 Small washer 1
13 Impact spring 1
14 Impact positioning sleeve 1
15 Upper impact block 1
16 Tapping screw 4
17 1
18 Torque stage positioning ring 1
19 Positioning spring strip 2
20 Torque Selector 1
21 Inner threaded ring 1
22 Spring 1
23 Washer 1
24 Ball group 16
25 Gear box 1
26 Ring gear 1
27 Shaft sleeve 1
28 Planet carrier 1
29 Planet gear 3
30 Washer 1
31 Speed positioning ring 1
32 Governor box 1
33 Screw 4
34 Movable ring gear 1
Part Description Q’ty
35 Speed control lever 1
36 Outer ring of governor box 1
37 Planet carrier 1
38 Planet gear 3
39 Planet carrier 1
40 Planet gear 3
41 Fixed ring gear 1
42 Washer 1
43 Screw 2
44 1
45 Motor 1
46 1
47 Speed Selector 1
48 Decoration plate 1
49 Bit holder 2
50 Driver bit 2
51 1
52 1
53 Direction Selector 1
54 Switch 1
56 Ball Ø4 1
57 Spring 1
58 1
59 1
60 Right Housing 1
61 Tapping screw 3
62 Conducting strip 3 1
63 Conducting strip 2 2
64 1
65 Tapping screw 8
66 Right Foot plate 1
67 Contact plate 1
68 Contact strip 2
PARTS LIST
