Page 7For technical questions, please call 1-888-866-5797.Item 69652
Specifications
Charger and Battery
Charger Input Rating 120VAC / 60Hz
Battery Rating 18V / 1300mAh
Battery Type NiCd
Charging Time 3-5 hours
Battery Runtime 12 hours
Drill
No Load Speed 0-900 RPM
Settings
20 Torque Settings
1 Drill Setting
Chuck Capacity 3/8" Keyless
Light
LED Bulb 9 Bulbs, 115 Lux each
Adjustment 0-90°, three position
Setup - Before Use
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Diagram on page 12.
Functions
Keyless Chuck
Torque Adjustment Ring
Work Light
Trigger
Direction
Switch
Battery Pack
Battery Button
Power
Button
Handle
Lens
Cover
Figure A
SAFETYOPERATIONMAINTENANCE SETUP
