Page 14 For technical questions, please call 1-800-444-3353. Item 91062
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty.
1 Name Plate 1
2 Tap Screw (8SEABB04-18) 3
3 Belt Cover 1
4 Belt 1
5 Bearing Sleeve 1
6 Bearing (8SG6000Z-01) 1
7 Press Board 1
8 Tap Screw (8SEABB04-8) 2
9 Large Pulley 1
10 Small Pulley 1
11 Tap Screw (8SGABB04-8) 2
12 Press Board 1
13 Bearing (8SG608Z-01) 1
14 Bearing Sleeve 1
15 Left Housing 1
16 Trigger 1
17 Safety Lock Button 1
18 Power Switch 1
19 Handle Cover 1
20 Tap Screw (8SEABB04-18) 2
21 Power Cord 1
22 Spring 1
23 Stator 1
24 Tap Screw (8SEABB04-60) 2
25 Armature 1
26 Wind Shield 1
27 Bearing (8SG608G-01) 1
28 Bearing Sleeve 1
29 Tap Screw (8SEABB04-14) 2
30 Press Cord Board 1
31 Press Cord Shield 1
32 Screw Arbor 1
Part Description Qty.
33 Screw Arbor 1
34 Spring 1
35 Carbon Brush Cap 2
36 Carbon Brush 2
37 Carbon Brush Sleeve 2
38 Carbon Brush Holder 2
39 Rear Cover 1
40 Stopper 1
41 Dust Port Cover 1
42 Tap Screw (8SEABB04-18) 3
43 Label 1
44 Tap Screw (8SEABB04-18) 9
45 Right Housing 1
46 Nut (M5) 4
47 Guide Lock Knob 1
48 Depth Knob 1
49 Tap Screw (8SEABB04-14) 1
50 Knob Body 1
51 Dial 1
52 Adjustable Nut 1
53 Adjustable Spring 1
54 Front Base Plate 1
55 Cylinder Pin 1
56 Press Blade Plate 2
57 Knife 2
58 Set Screw 4
59 Knife Holder 2
60 Knife Holder Bolt 6
61 Rear Base Plate 1
62 Bearing (8SG608Z-01) 1
63 Knife Drum 1
64 Guide (Not Shown) 1
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
