Page 8 For technical questions, please call 1-800-444-3353. Item 91062
SAFETY OPERATION MAINTENANCESETUP
Specifications
Electrical Requirements 120VAC / 60Hz / 5.5A
Drum Speed 16,000 RPM
Cutting Speed 32,000 Cuts per minute (2-knife drum)
Max. Planing Width 3-1/4″
Max. Planing Depth 1/16″ Per Pass (Adjustable)
Dust Chute Dim. 1-1/2″ I.D. x 1-11/16″ O.D.
Number of Blades 2
215530
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Make sure that the Trigger is in the off-position and unplug the tool from its
electrical outlet before performing any procedure in this section.
Note: For additional information regarding the parts listed in the
following pages, refer to Parts List and Diagram on page 14.
Functions
Safety Lock
Button
Depth
Knob
Guide Lock
Knob
Guide
Dust Port
Cover
Trigger
