Titan LTE Owners Handbook (Issued 07/17)
Suggestion
Fully charge the battery for 12 hours before use. Failure to do so could impair the
battery performance and may permanently reduce the battery’s longevity.
DISASSEMBLY FOR TRANSPORT
The powerchair can be quickly and easily separated into 4 sections: seat assembly, front section, and
rear section (with or without batteries) and the battery pack.
1. Unplug the joystick from the rear of the
powerchair.
2. Swivel the seat using the lever whilst lifting up
the seat to remove. The chassis can now be
split. If you need to remove the batteries follow
steps 3 and 4, otherwise proceed to step 5.
3. Loosen and remove the two knobs on the
shroud. Lift up the front shroud to remove. Lift
up the front shroud to remove.
4. Disconnect the batteries and lift up the
battery pack to remove.
5. Lift up the yellow handle to separate the
chassis. This can be done with or without
the batteries installed.
