Drive 13029 - Assembly Instructions; Step 1: Attach Top Leg to Bottom Leg; Step 2: Install Post into Base; Step 3: Attach Hook to Post

1
2
3
F
B
E
D
C
G
H
A
Overlay top leg (A) with pre-assembled
pin (F) over corresponding holes in the
middle of the boom leg (B) Hammer
the pin (F) into boom leg and making
sure that it’s ush with the top leg.
Place lock washer (D) onto bolt (E) and
install from the boom side of the base
into boom of post (C).
Snap the hook (G) over the top end of
post (C) until the snap pins pop through
the two holes in the tube portion of the
hook.
assembly instructions
parts list
© 2006 Medical Depot, Inc. All rights reserved.
Drive is a trademark of Medical Depot, Inc.
Port Washington N.Y. 11050 USA Made in China
code description qty
a.
b.
c.
d.
e.
Top Leg (w/insert)
Boom Leg
Post
Lock Washer
Lock Washer
1
1
1
1
1
