ASSEMBLY INSTRUCTIONS
INSTALL MOTORS
3. Hold the bed securely, positioned with motor cams up, as shown below.
4. Position the motor over both cams.
5. Tap either end of the motor housing (shown below) with enough force to snap
the motor assembly into position on the cam.
Note: This is a bearing surface requiring a tight fit; it may require a hardy hit
with palm of hand to snap over motor tube.
6. Repeat step 5 for other end of motor.
INSTALL MOTOR SLIDE CAPS
7. Position the caps as shown on page 9 so that the grooves in the slide cap are
aligned with the grooves in the motor.
8. Apply straight downward pressure to each end of the cap while sliding into the
closed position.
9. Repeat step 8 for the other cap.
10. Ensure that all four corners of each slide cap are engaged.
5
