assembly instructions
1. Remove contents from carton.
2. Insert front tiller into front of frame (figure 1).
3. Once tiller is in place and handles are aligned
correctly with the wheels, tighten the screw
(figure 2) using an allen key by turning clockwise.
4. Straighten tiller to the upright position. Slide second
screw into receptacle (figure 3)
5. Secure scew and tiller in place by pushing locking
handle against the side of the tiller (figure 4).
6. Insert seat post into seat receptacle on frame. Set
to desired height and secure in place by inserting
thumb screw and turning clockwise until tight.
figure 1
figure 2
figure 3
figure 4
