Drive 790 - Hand Brake System; Brake Operation and Locking; Hand Brake Adjustment; Adjusting Knee Walker Height

To adjust the handle height, release the lock tab on the
collar and adjust the handle to the desired height. Push
the lock tab back to tighten.
To adjust the seat height, turn the adjustment knob
located under seat counterclockwise until free of frame.
Set seat to desired height and return adjustment knob.
Turn clockwise to tighten.
To fold the tiller down, pull the boom lock lever away
from the knee walker until the lock is disengaged. While
holding the lock lever in the down position, fold the tiller
down until it rests on the knee pad.
Do not use the Knee Walker if the brake system is not
working properly.
- The Knee Walker’s brake is similar to a bicycle and
also has a locking feature.
- To use the brake, simply pull the lever with your
finger tips toward the handle bar.
- To lock the brake, pull the brake lever towards the
handlebar and push down spring loaded push buon
(located on top of brake). When done correctly, push
buon with remain down and brake lever will be
locked in place. Repeat for other brake.
- To release brake, simply pull lever towards the handle
bar. Push pin will pop upautomatically.
using the hand brake
adjusting the hand brake
- For minor adjustment the brake adjuster located on
the handbrake can be turned out from the hand
brake countercockwise to tighten the brake, or
clockwise to loosen the brake. Keep the cable
adjuster nut against the hand brake.
- If further adjustment is required, apply the same
method of adjustment at the lower cable adjuster.
- As you adjust the cable adjuster and the adjuster nut
away from each other the brakes will tighten, and as
you adjust them closer the brakes will loosen.
adjusting handle height
adjusting seat height
to fold tiller
