Ambassador Electric Scooter Page 13 of 16 Owner’s Handbook (Code: Ambassador_IFU)
8 TROUBLESHOOTING
The troubleshooting guide is also featured on page
1 of the Owner’s Handbook.
Problem: Scooter will not switch on
Symptoms:
Batteries not connected
Circuit breaker has tripped
Remedy:
Check batteries connected
Push circuit breaker to reset
Problem: Scooter will switch on but will not run
Symptoms:
Flat batteries
Charger plugged in
Motor in freewheel mode
Remedy:
Recharge battery
Unplug charger from scooter
Push down freewheel lever
Problem: Scooter appears slow
Symptoms:
Flat batteries
Speed setting slow
Remedy:
Recharge battery
Turn up speed dial
Problem: Seat moves whilst in use
Symptoms:
Seat not locked in position
Remedy:
Slowly rotate the seat until it
drops in place and is secure.
Problem: Horn sounds involuntarily / automatically
Symptoms:
The scooter has diagnosed a
fault
Remedy:
Ensure the wigwag paddle is
released and switch the
scooter off and on.
Recharge batteries if error
persists.
If the scooter has diagnosed a fault the speed display
will flash and the horn beep in sequence. If this occurs,
count the number of flashes and refer to the table
below.
1. Low Battery. Charge batteries as soon as
possible.
2. Low Battery Voltage. As above
3. High Battery Voltage. Remove charger if plugged
into the scooter.
4. Current Time-Out. The scooter has drawn too
much power for too long. Switch switch off and
restart after 5 minutes.
5. Brake Fault. Check the freewheel lever is in the
DRIVE position
6. Wigwag Paddle. Release paddle, switch off the
scooter and restart without pressing the paddle.
If any other errors are shown contact your dealer.
9 SPECIFICATION
Model Reference
Ambassador
Dimension
(L x W x H)
145cm x 66cm x 120cm
57” x 26” x 47¼”
Total weight
Without battery
116kg (255lb)
86kg (189lb)
Propulsion motor
600W / 0.8hp
Battery
12V 50ah x 2
Charger
24V 5A
Controller
Dynamic Rhino II 120A
Front Suspension
2x shock absorber
Rear Suspension
1x shock absorber
Front Tyre
3.00 x 8 x 2
(14” / 36cm diameter)
Rear Tyre
3.00 x 8 x 2
(14” / 36cm diameter)
Anti-tip Wheel
2.75”/ 7cm diameter
Top Speed (Forward)
12.8kph / 8.0mph
Climbing angle
8º
Cruising range (see note)
40km / 25 miles
Min. turning radius
134cm (53”)
Ground clearance
10cm (4”)
Kerb climbing ability
Obstacle climbing ability
Max. load weight
(including goods)
160kg / 25 stone
Remark:
Drive Medical reserves the right to modify the
specification if necessary. The final specification is
subject to the individual scooter you purchase from
your dealer.
Note:
The maximum driving distance is based on an ambient
temperature of 20ºC, a 100kg driver, a fully charged
battery and a constant driving speed at 12.8kph/h with
70% battery power discharged. The surface is flat and
even.
