Ambassador Electric Scooter Page 4 of 16 Owner’s Handbook (Code: Ambassador_IFU)

Warning
Mounting an obstacle at speed will cause a jolt
to the scooter which may cause discomfort or
injury to the user. If you are in any doubt, do
not mount the obstacle whilst moving.
Labelling
Please carefully read all labels applied to the
scooter before driving. For future reference, do not
remove them from the scooter. The labels are also
shown below:
!
!
!
!
To adjust tiller angle, press
the paddle and pull the tiller.
Do not adjust the tiller angle,
whilst the scooter is moving
Always check the tiller is
locked in the correct position
before using
Do not lean on the tiller whilst
mounting or dismounting from
the scooter
C A U TIO N
Located on tiller
Located on rear
Located by freewheel lever
CARELESSNESS CAUSES FIRE
DRIVE MEDICAL HX5 9JP
To comply with the Furniture and
Furnishings (Fire) (Safety) Regulations:
This article does not include a Schedule
3 interliner.
All foams, fillings and composites have
been tested to ensure compliance with
the relevant ignitability test. All covers
and fillings have been tested to ensure
that they are cigarette resistant. All
covers have been tested to ensure that
they are match resistant.
Further details are available
From your retailer.
Located on seat
WARNING
Do not push both RH&LH side of the
speed control lever simultaneously.
This might leave you unable to
control your scooter.
Located on top of tiller
Electromagnetic Interference
Scooters may be susceptible to electromagnetic
interference (EMI) from sources such as mobile
phones, walkie-talkies, TV and radio broadcast
stations and amateur radio sets. In some cases,
there is a risk this interference may cause
involuntary movement of the scooter. The scooter
has been tested and passed to withstand
interference to a level of 20V per metre.
Be aware that the above sources may cause
involuntary movement due to EMI. Exercise caution
whilst using the aforementioned devices and avoid
close proximity to TV and Radio broadcast stations.
The addition of components or accessories may
affect the EMI susceptibility of the scooter. Do not
fit accessories other than Drive Medical authorised
accessories.
WARNING:
EMI
REFER TO
OPERATORS
MANUAL FOR
INFORMATION
THIS UNIT HAS
ACHIEVED 20 V/m
EMI TESTING
REF AMB8BL
S/No
Drive Medical Ltd (HX5 9JP)
Drive Medical GmbH (D-88316)
Maximum User Mass 160kg
5 06 0 26 6 8 48 9 57
MADE IN
TAIWAN

Drive Ambassador Specifications

General

Weight Capacity	120 kg
Overall Length	1200 mm
Overall Width	600 mm
Drive Wheels	Rear
Range	40 km
Max Load	120 kg
