DROPSA SMART3 User Manual

21
N.B. The following specifications apply for all models:
Bypass calibration pressure 25 bar; Pressure switch 18 bar; Pressure gauge 0 – 100 bar.
12.3 Connector ACCESSORIES
ITEM
DESCRIPTION
PART NUMBER
CONNECTOR M12 X 1
4 poles plug connector -female
0039169
CONNECTOR M12 X 1
5 poles plug connector -female
0039170
DIN 43650 CONNECTOR
3 poles /heart connector –PG9 output cables
0039976
DIN 40050 CONNECTOR
3 poles / heart -female- miniaturizated connector
0039841
12.2 SPARE PARTS
ITEM
DESCRIPTION
PART NUMBER
PUMP
180 DC flow rate
3099166
MOTOR
110Vac 50/60Hz single-phase - 140/175W 2P(2800/3500 rpm)
3301565
230Vac 50Hz single-phase - 135W 2P(2800 rpm)
3301567
230Vac 60Hz single-phase - 170W 2P- (3500 rpm)
3301600
24Vdc - 55W (2800 rpm)
3301582
SENSOR LEVEL
Magnetic
1655763
Optical
1639201
RESERVOIR
2 L
6770102
3 L
6770033
FILTER
1000µ grade
3130466
PRESSURE GAUGE
0 -100 bar
0020564
PRESSURE SWITCH
NA 10÷20 bar set.18bar
3291048
NC 10÷20 bar set.18bar
3291035
CONTROL PCB
110Vac
1639225
230Vac
1639224
24Vdc
1639226
SMART3 - AUTOMATIC VERSION-ON BOARD CONTROLLER
LEVEL
ALARM
RESERVOIR
CONNECTOR
PLATE
VOLTAGE
DESCRIPTION
PART
NUMBER
Magnetic
for oil
Contact
NO/NC
2L
Type 1
3133807
24Vdc
SMART3-AUT-24V-2L-FL-NC/NO
4011018
110Vac-50/60Hz
SMART3-AUT-110V-2L-FL-NC/NO
4011118
230Vac-50Hz
SMART3-AUT-230V50-2L-FL-NC/NO
4011218
230Vac-60Hz
SMART3-AUT-230V60-2L-FL-NC/NO
4011618
3L
24Vdc
SMART3-AUT-24V-3L-FL-NC/NO
4011318
110Vac-50/60Hz
SMART3-AUT-110V-3L-FL-NC/NO
4011418
230Vac-50Hz
SMART3-AUT-230V50-3L-FL-NC/NO
4011518
230Vac-60Hz
SMART3-AUT-230V60-3L-FL-NC/NO
4011718
Optical for
oil/fluid
grease
Contact
NO/NC
2L
Type 2
3133806
24Vdc
SMART3-AUTC-24V-2L-OP-NC/NO
4011019
110Vac-50/60Hz
SMART3-AUTC-110V-2L-OP-NC/NO
4011119
230Vac-50Hz
SMART3-AUTC-230V50-2L-OP-NC/NO
4011219
230Vac-60Hz
SMART3-AUTC-230V60-2L-OP-NC/NO
4011619
Contact
NO/NC
3L
24Vdc
SMART3-AUTC-24V-3L-OP-NC/NO
4011319
110Vac-50/60Hz
SMART3-AUTC-110V-3L-OP-NC/NO
4011419
230Vac-50Hz
SMART3-AUTC-230V50-3L-OP-NC/NO
4011519
230Vac-60Hz
SMART3-AUTC-230V60-3L-OP-NC/NO
4011719
AUTOMATIC VERSION - SMART&SIMPLE
LEVEL
ALARM
RESERVOIR
CONNECTOR
PLATE
VOLTAGE
DESCRIPTION
PART
NUMBER
Optical for
oil/fluid
grease
Contact
NO/NC
2L
Type 1
3133807
24Vdc
SMART3-SIMP-24V-2L-OP-NC/NO
4012018
110Vac-50/60Hz
SMART3-SIMP-110V-2L-OP-NC/NO
4012118
230Vac-50Hz
SMART3-SIMP-230V50-2L-OP-NC/NO
4012218
230Vac-60Hz
SMART3-SIMP-230V60-2L-OP-NC/NO
4012618
3L
24Vdc
SMART3-SIMP-24V-3L-OP-NC/NO
4012318
110Vac-50/60Hz
SMART3-SIMP-110V-3L-OP-NC/NO
4012418
230Vac-50Hz
SMART3-SIMP-230V50-3L-OP-NC/NO
4012518
230Vac-60Hz
SMART3-SIMP-230V60-3L-OP-NC/NO
4012718
