DS18 DDX9AD User Manual

17
DDX9AD
SPECIFICATIONS
14.4V DC (10.8V to 15V operation)
10 Amp
Chassis: 178mm x 50mm x 118mm
Bezel frame: 170mm x 46mm x 10mm
Screen Size: 233mm x 148mm x 35mm (overall)
Weight: 1.66 Kg
4 Core Processor / 2 Gb RAM / 32 Gb Memory
Android Q (Version 10)
9 inch / Wide 16:9
1024 x 600
IPS / WSVGA / Capacitive Touch Screen
-20
o
C to +60
o
C (14
o
F to 140
o
F)
40W x 4 Ch / 4 ohm
15W x 4 Ch / 4 ohm
2.5 Volts (Front and Subwoofer)
10 bands (35Hz, 60Hz, 80Hz, 120Hz, 160Hz,
250Hz, 320Hz, 400Hz, 600Hz, 800Hz, 1KHz, 3KHz,
5KHz, 8KHz, 12.5Khz, 16Khz)
+/- 12dB
Selectable (80Hz, 120Hz, 160Hz, Off) Slope: 12
Volume / Balance / Fader / Subwoofer Level
FM: 87.5 ~ 107.9 KHz AM: 530 ~ 1710 KHz
30 Stations (18 FM/12 AM)
Selectable (USA, Latin, Japan, Asia, Europe,
OIRT, Australia, Mid-East)
LOC (On/Off) / ST (On/Off)
V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
RMVB, MPG4, AVI, MP3, WMA, JPEG, DivX
1080P Video
up to 64 Gb
1.5 Amp (USB)
3 (1 x Front, 2 x Rear)
V4.1 / Audio Streaming / Hands Free calls
Built-in
RCA Analog Video up to HD 720p (Front/Rear)
Dual RCA (1 Volt/75 ohm)
Rear RCA Audio and Video /
Front 3.5mm Jack Stereo Audio
3.5mm Jack external MIC Input
Frontal IR Receptor / Wired Input / CAN-Bus Protocol
General:
Rated power source: 14.4V DC (10.8V to 15V operation)
Maximum Current Consumption: 10 Amp
Dimensions (W x H x D):
Hardware:
Software:
Bezel frame: 170mm x 96mm x 5m Weight:1.5 Kg
Display:
Screen Size / Aspect Ratio: 6.2 inch / Wide 16:9
Pixels: 800 x 480
Display Type: TFT / WVGA / Capacitive Touch Screen
Temperature Operation: -20
o
C to +60
o
C (14
o
F to 140
o
F)
Audio:
Maximum Power Output: 40W X 4 Ch / 4 ohm
Continuous Power Output: 15W x 4 Ch / 4 ohm
Pre-output Level: 3.8 Volts (Front, Rear and Sub-W)
Equalizer: 10 bands (32Hz, 64Hz, 128Hz, 256Hz, 512Hz,
1KHz, 2KHz, 4KHz, 8KHz, 16KHz)
Gain: +/- 12dB 12 dB/Oct
Subwoofer / LPF:
Audio Control / Loudness: Volume / Balance / Fader /
Subwoofer Level /Loudness
Tuner:
Frequency Range: FM:87.5 ~ 107.9 KHz AM: 530 ~ 1710 KHz
Presets Memory: 30 Stations (18 FM/12 AM)
Region: Selectable (USA, Latin, Japan, Asia, Europe,
OIRT, Australia, Mid-East)
Sensitivity Adjustment: LOC (On/Off) / ST (On/Off)
USB / SD Player:
Type / Class: V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported:
Resolution Supported: RMVB, MPG4, AVI, MP3, WMA, JPEG, DivX
Memory Size Reader: up to 64 Gb
Max Current Supply: 1.5 Amp (USB)
Number of USB Ports:
Connectivity:
Bluetooth Version / Services:
Wi-Fi:
Camera Input: RCA Analog Video up to HD 720p (Front/Rear)
Video Output: Dual RCA (1 Volt/75 ohm)
A/V Aux Input: Rear RCA Audio and Video /
Front 3.5mm Jack Stereo Audio
Microphone: 3.5mm Jack external MIC Input
Remote Control: Frontal IR Receptor / Wired (3.5mm jack) Input

DS18 DDX9AD Specifications

General

Brand	DS18
Model	DDX9AD
Category	Car Video System
Language	English
