Keypad Commands:
4.2 [*] Commands
15
[*] [3] Alarm Memory
The memory light will be on if any alarm occurred during
the last armed period or if an alarm occurred while the
panel was disarmed (24-hr zones). Instructions on view-
ing alarms in memory are located in the PC5010 CP-01
User’s Guide
(’Disarming the System’).
[*] [4] Door Chime On/Off
If enabled the keypad will beep 6 times rapidly when a
zone is tripped and restored. The panel will only do this
for zones with the Door Chime attribute enabled and if
the door chime feature is enabled
(see Section 5.4
Advanced Programming [101]-[132])
.
[*] [5] Programming Access Codes
All access codes can arm and disarm any partition they
are enabled for, and can activate the PGM outputs using
the [*][7] commands
(
see section ’[*] [7] Command Out-
put Functions’
)
.
For instructions on programming access codes, see the
Power Series User Guide
(‘Programming Access Codes’).
The available access codes are as follows:
General Access Codes - Access Codes [01] to [32]
Each access code can be used to arm and disarm the
assigned partitions. Additional access code attributes are
also programmable to determine what abilities the code
will have.
You can program partition assignments and access code
attributes by following the instructions in this section.
Duress Codes - Access Codes [33] and [34]
When a Duress Code is used to perform any function the
panel will send a Duress reporting code to the central sta-
tion
(see Section 5.3 Basic Programming [001]-[002] and
Section 5.6 Communicator Programming )
.
Supervisor Codes - Access Codes [41] and [42]
Supervisor Codes can program additional access codes.
By default, Supervisor codes have the same partition and
attribute programming as the Master code. You can
change the partition and attribute programming for these
codes by following the instructions in this section.
System Master Code - Access Code [40]
By default the System Master Code is enabled to operate
on all partitions, and can perform any keypad function.
This code can be used to program all access codes, includ-
ing the Supervisor Codes and Duress Codes.
If the Master Code Not Changeable
Master Code Not ChangeableMaster Code Not Changeable
Master Code Not Changeable option is enabled the
System Master Code can only be changed using Installer
Programming.
Maintenance Code
The maintenance code can only be used to arm and dis-
arm the system. It cannot be used to bypass zones, to
access the Escort5580(TC), or to cancel or postpone auto-
matic arming. The code can only be programmed in
Installer Programming.
Programming Partition Assignments and Access
Code Attributes
You can enable or disable each access code to work on
each partition. Additional access code attributes are also
programmable. Attributes determine what abilities the
code will have.
By default, each code has the attributes of the code used
to program it. For example, if you use the Master Code to
program other access codes, the new codes will have the
same attributes as the Master Code. You can change the
partition and attribute programming by following the
instructions described below.
You cannot change Master Code partition or attribute
programming. The Master Code has all partitions and all
attributes turned on, except for the Bell Squawk on Arm-
ing/Disarming attribute.
To program which partition(s) each code will work on:
1. Enter [*][5][Master Code][8] to enter partition programming.
2. Enter the 2-digit number of the access code you want to
edit.
3. Enter the partition number (1-2) to toggle it on or off.
NOTE:
Partition programming is NOT supported at the fol-
lowing keypads: PC5508(Z), PC5516(Z), PC5532(Z) versions
v2.00 and lower; LCD5500(Z) version 2.x and lower;
LCD5501Z version 1.x and lower.
To program each attribute:
1. Enter [*][5][Master Code][9] to enter the attribute pro-
gramming mode.
2. Enter the 2-digit number of the access code you want to
edit.
3. Enter the attribute number to toggle it on or off.
The programmable attributes are as follows:
• Attributes 1-2
Attributes 1-2Attributes 1-2
Attributes 1-2: For Future Use.
•Attribute 3
Attribute 3Attribute 3
Attribute 3: Zone Bypass enabled.
This attribute allows the user to bypass zones.
•Attribute 4
Attribute 4Attribute 4
Attribute 4: Escort5580(TC) Remote Access
This attribute allows the user to access the security sys-
tem via the Escort, if installed.
•Attribute 5
Attribute 5Attribute 5
Attribute 5: Downlook Remote Trigger to Telephone
Number 1. For use with the Escort5580(TC) and the
PC5108L/DLM-4L (see the
PC5108L Installation Man-
ual
for details).
•Attribute 6
Attribute 6Attribute 6
Attribute 6: Downlook Remote Trigger to Telephone
Number 2. For use with the Escort5580(TC) and the
PC5108L/DLM-4L (see the
PC5108L Installation Man-
ual
for details).
• Attribute 7
Attribute 7Attribute 7
Attribute 7: Bell Squawk on Arming/Disarming. When
this attribute is turned on, the bell will squawk when the
access code is entered to arm or disarm the system. For
example, you can use the arm/disarm bell squawk
attribute to have wireless key access codes squawk the
bell, while other codes are silent. To do this, enable
attribute [7] on all access codes associated with wireless
keys.
NOTE:
If you enable the Bell Squawk on Arming/Disarm-
ing option (section [014], option [1]), the bell will sound
arm/disarm bell squawks for all access codes, regardless of
the programming for attribute [7] (See Section 5.3 Basic
Programming PWS Sect 3 [001]-[002] and Section 5.4
‘Advanced Programming’).
7
Device Low Battery:
A wireless device has a low battery condition. Press [7] one, two, or three times to view which devices are experiencing bat-
tery failure. An LED keypad will indicate battery failure using zone lights. The following will occur:
Keypad beeps: Keypad displays:
Press [7] 1) Zones with low batteries (LED keypad - zone lights 1 to 32)
Press [7] again 2) Handheld keypads with low batteries (LED keypad - zone lights 1 to 4)
Press [7] again 3) Wireless keys with low batteries (LED keypad - zone lights 1 to 16)
8
Loss of System Time:
When the panel is powered up, the internal clock needs to be set to the correct time. This trouble is cleared when an
attempt is made to reset the clock. This is set in ‘[*][6] User Functions’ Programming on page 16.
Light Trouble
