[006]-[008] Special Access Codes
These sections require 4 or 6 digits to be entered.
[006] - Installer Code
Installer Lockout Enable . . . . . . . . . . . . . . . . . . . . . . Section [990]
Installer Lockout Disable . . . . . . . . . . . . . . . . . . . . . . Section [991]
[007] - Master Code
[008] - Maintenance Code
This is an Arm/Disarm only code. It can not be used to
bypass, activate [*][7] outputs, program other user codes
or enter the [*][6] menu. It can access and arm through the
Escort5580(TC). Openings or Closings using this code
report as a Special Opening/Closing and will log to the
event buffer as ’Maintenance Code’.
[009]-[011] Programmable Output Options
Programmable outputs are programmed with a two digit
code indicated in the table below. Programmable outputs
are available on the following devices:
• PGM 1, PGM 2 on the PC5010 CP-01 main board
• 8 low current outputs available with the PC5208 out-
put module
• 4 high current outputs available with the PC5204
power supply/output module
• Section [009] is used to program the PGM outputs on
the PC5010 CP-01.
• Section [010] is used to program the PGM outputs on
the PC5208.
• Section [011] is used to program the PGM outputs on
the PC5204.
Programming any of the outputs is a three step process:
1. Select an option from the list below for the PGM output.
2. Select the output attributes for the PGM output.
3. Select the partitions on which the PGM output will operate.
The following is a list of the programmable output
options and attributes.
PGM Attribute Programming . . . . . . . . . . . . . . Section [501]-[564]
[009] - [011] PROGRAMMABLE OUTPUT OPTIONS
Option Output Description
01 Burglary and Fire Bell
Follower
This output will activate when the Bell output is active and will turn off when the alarm output is silenced. If the
alarm output is pulsing, the PGM output will pulse as well. This PGM output will follow:
• Fire Pre-alerts
• Temporal Three Fire Signal (if enabled)
• All Burglary and Fire Alarms by partition
•Bell Time-out
This output will NOT follow Bell Squawks of any kind. The Main Bell will still activate for all alarms; the PGM out-
put will only activate for alarms for the partition it is assigned to.
NOTE: The Fire Bell has precedence over Burglary. If a fire alarm occurs on partition X, and partition Y
already has a Burglary Alarm active (’Burg’ PGM active on partition two), the Fire and Burg output on
partition Y will pulse (’Fire’ PGM) with the Main Bell. Silent alarms will be audible if either partition is
in an audible alarm condition.
02 Not Used For Future Use
03 Sensor Reset This output will normally be active. This option is used to reset power for latching smoke detectors. The output
will deactivate for five seconds when the [*] [7] [2] command is entered (see section ’[*] [7] Command Output
Functions’). The keypad buzzer will not sound for the five second period.
Refer to the Control Panel Wiring Diagram in this manual for wiring instructions.
NOTE: Only ONE of options [03] Sensor Reset and [20] [*] [7] [2] Command Output Option [2] may be
programmed on the same system.
04 Two-Wire Smoke Reset
(PGM2 only)
Allows 2-wire smoke detectors to be connected; refer to the wiring diagram on page iv, [*][7][2] to reset.
05 System Armed Status The output will activate when the partition or system is armed and deactivate when disarmed. If this output is
assigned to both partitions, all partitions must be armed for the output to activate.
06 Ready To Arm The output will activate when the partition or System is ready to arm (all non-force armable zones on the system
are restored). The output will deactivate when an access code is entered to arm the system and the Exit Delay
begins.
07 Keypad Buzzer Follow This output will activate when any of the following events occurs and will remain active for as long as the keypad
buzzer is active: Door Chime, Entry Delay, Audible Exit Delay, Auto-arm Prealert and 24-hr Supervisory Buzzer Zone
08 Courtesy Pulse This option provides an output which activates for the entry and exit times, plus 2 minutes. It can be used to turn
on a courtesy light near the exit door for the duration of the entry / exit times. If more than one courtesy pulse
output is required, they all must be programmed for global operation (PGM attributes 1 and 2 enabled).
09 System Trouble The output will activate when any of the selected Trouble conditions are present. It will deactivate when all the
selected Trouble conditions are cleared. The PGM attributes for this option, programmed in Sections [141] to
[142], differ from the standard selection of attributes normally programmed in sections [501] to [514]. Program
which Trouble conditions will activate the output by selecting some or all of the following attributes:
Bit [1] Service Required* Bit [5] Fire Trouble / Zone Fault
Bit [2] AC Failure Bit [6] Zone Tamper
Bit [3] Telephone Line Trouble Bit [7] Zone Low Battery
Bit [4] Failure to Communicate Bit [8] Loss of Clock
*Battery, bell, general Trouble, general tamper, general supervisory
