Programming Sections:
5.9 International Programming PWS Sect 9
43
[701] FIRST INTERNATIONAL OPTION CODES
Option International Code On/Off Description
1 AC ON 50 Hz AC
. - The incoming AC power cycles at 50 Hz.
OFF 60 Hz AC
. - The incoming AC power cycles at 60 Hz.
2 Time Base ON The timebase is the internal crystal oscillator.
In cases of unstable AC power input, the
internal crystal can be used to keep the most accurate timebase.
OFF The timebase is the AC power input.
The 50 or 60 Hz AC power input is normally very stable
and can be used as the timebase
3 Arming Inhibit ON AC/DC Arming Inhibit with Battery Check Enabled.
When an AC or DC Trouble is present,
the system will not arm. This includes Keypad, Keyswitch, Automatic, and Downloading arming.
If enabled and arming is attempted, the system will perform a system battery check as well as a
battery check on all peripheral modules supported by a backup battery.
OFF Arming not Inhibited
. The system can be armed, regardless of the presence of an AC or DC
Trouble and will not check all system batteries upon arming.
NOTE: If this option is enabled, it is strongly recommended that AC Troubles be dis-
played (Section [017], Option 1 ON).
4 Latching System Tamper ON System Tampers Require Installer Reset and Inhibit Arming
If any system Tamper condition
occurs, the Installer Code must be entered [*][8] [Installer Code] and the Tamper condition must
be restored before the system can be armed. This includes Auto-arming and keyswitch. If Auto-
arming is attempted with a latched tamper, the panel will not arm. The Auto-arm cancellation
code is not transmitted however because a user did not cancel the Auto-arming sequence.
OFF System Tampers Do Not Require Installer Reset.
If enabled, the manual bypassing of a zone
will not bypass the tamper or fault states (DEOL). This feature also applies to Zone Faults.
5 Access Code Length ON 6-digit Access Codes
. All access codes on the system will be 6 digits in length except the Panel
I.D. Code and the Downloading Access Code.
• System Master Code = XXXX56 XXXX = previous code, (1234)
• Installer Code = YYYY55 YYYY = previous code, (5555)
OFF 4-digit Access Codes
. All access codes on the system will be 4 digits in length. For any existing
codes, the last 2 digits are removed.
6 Busy Tone ON Busy Tone Detection Enabled.
If these tones are detected, the communicator will disengage
the phone line and try to place the call again following the Delay Between Dialing Attempts.p
OFF Busy Tone Detection Disabled.
The communicator will use the standard dialing procedure for
every attempt.
7 Battery Current Charge ON High Current Battery Charge.
Approximately 650-700 mA.
OFF Standard Current Battery Charge.
Approximately 350 mA.
8ONFor Future Use
[702] SECOND INTERNATIONAL OPTION CODES
Option International Code On/Off Description
1 Pulse Dial ON Pulse Dialing Make/Break Ratio is 33/67
OFF Pulse Dialing Make/Break Ratio is 40/60
2 Force Dial ON Force Dialing Enabled.
If the first attempt by the panel to call the monitoring station fails to
detect a dial tone, on every subsequent attempt the panel will dial regardless of the presence of
dial tone. See {703] Delay Between Dialing Attempts
OFF Force Dialing Disabled.
The panel will not dial the programmed telephone number if dial tone
is not present.
3 Land Line Test Transmission ON Land Line Test Transmission Interval is in Minutes
. The value programmed in Section [370]
seventh entry is in minutes.
OFF Land Line Test Transmission Interval is in Days.
The value programmed in Section [370] Sev-
enth entry is in days.
4 Handshake ON 1600 Hz Handshake.
The communicator responds to a 1600 Hz handshake for bps formats.
OFF Standard Handshake.
The communicator responds to the handshake designated by the for-
mat selected (1400 or 2300 Hz).
5 I.D. Tone ON I.D. Tone Enabled.
After the telephone number is dialed, the panel will emit a tone (as speci-
fied by Option 6) for 500ms every 2 seconds to indicate that it is a digital equipment call, not
voice.
OFF I.D. Tone Disabled.
6 I.D. Tone Frequency ON 2100 Hz I.D. Tone
OFF 1300 Hz I.D. Tone
7 DLS Window ON One Time 1-hour User-enabled DLS Window.
The user-enabled DLS Window is 1 hour in
length and will be closed after a successful hang-up from a downloading call.
OFF Full 6-hour User-enabled DLS Window.
The user-enabled DLS Window is 6 hours in length
and remains open after a successful hang-up from a downloading call. This option determines
the length of the DLS window available on power up.
8 FTC Bell ON Bell on FTC when armed.
If a Failure to Communicate Trouble is generated while the system is
armed, the Bell output will sound for the length of Bell time-out or until the system is disarmed.
OFF FTC Trouble only when armed.
If a Failure to Communicate Trouble is generated while the
panel is armed, the Bell output will not sound but the keypad buzzer will sound Trouble beeps
until a key is pressed.
