Self Contained Wireless Alarm System v1.0
16
7.2 Programming Worksheets
Keypad and Function Key Programming
[000] Function Key Programming
[1] Function Key 1 Assignment
[2] Function Key 2 Assignment
[3] Function Key 3 Assignment
[4] Function Key 4 Assignment
[5] Function Key 5 Assignment
Function Key Options:
[001]-[002] Zone Definitions
Unless indicated otherwise, default values apply to NA, EU and CP-01
SIA FAR CP-01 defaults are indicated in gray text.
EU Defaults are indicated by a Superscript EU e.g., (
EU
) or (
EU
005)
NA Defaults are indicated by a Superscript NA e.g., (
NA
) or (
(NA
005)
See “Local Keypad Programming” on page 30. for additional options.
00 Null Key
09 Future Use *27 Disarm
01
Future Use
10 Future use *29 [A]uxilliary Alarm
02
Future Use
11 Future use *30 [P]anic
03
Stay Arm
12 Future Use
04
Away Arm
13 [][7][1] Command Output #1
* Applies to Key Fobs only
05
[][9] No Entry Arm
14 [][7][2] Command Output #2 See Section [804] Subsection [61]-[76]
06 [][4] Chime On / Off
15 For Future Use
07
Future Use
16 [][0] Quick Exit
08
[][1] Bypass Mode
17 [][1] Reactivate Stay/Away Zones
Key 1 Key 2 Key 3 Key 4 Key 5
Keypad Defaults
03 ___ 04 ___ 06 ___ 08 ___ 16 ___
00 Null Zone (Not Used) 13 24 Hour Gas* 25 Interior Delay*
01 Delay 1* 14 24 Hour Heat* 26 24 Hour Non-alarm*
02 Delay 2* 15 24 Hour Medical* 27-31 Future Use
03 Instant* 16 24 Hour Panic* 32 Instant Stay/Away*
04 Interior* 17 24 Hour Emergency* 33-35 Future Use
05 Interior, Stay/Away* 18 Future Use 36 24 Hr. Non-latching Tamper
06 Delay, Stay/Away* 19 24 Hour Water* 37 Night Zone
07-08 Future Use 20 24 Hour Freeze* 87 Delayed 24 Hr. Fire (Wireless)**
09 24 Hour Supervisory (Hardwired) 21 Future Use 88 Standard 24 Hr. Fire (Wireless)**
10 24 Hour Supervisory Buzzer* 22 Momentary Keyswitch Arm* 89 Auto-verified 24 Hr. Fire (Wireless)**
11 24 Hour Burglary* 23 Maintained Keyswitch Arm (Hardwired)*
12 Future Use 24 Future Use
*For burglary applications only ** For residential fire applications only
Section Zone Default Section Zone Default Section Zone Default Section Zone Default
[001]
01 01
I_____I_____I
[001]
09 00
I_____I_____I
[002]
17 00
I_____I_____I
[002]
25 00
I_____I_____I
02 03
I_____I_____I
10 00
I_____I_____I
18 00
I_____I_____I
26 00
I_____I_____I
03 03
I_____I_____I
11 00
I_____I_____I
19 00
I_____I_____I
27 00
I_____I_____I
04 03
I_____I_____I
12 00
I_____I_____I
20 00
I_____I_____I
28 00
I_____I_____I
05 04
I_____I_____I
13 00
I_____I_____I
21 00
I_____I_____I
29 00
I_____I_____I
06 04
I_____I_____I
14 00
I_____I_____I
22 00
I_____I_____I
30 00
I_____I_____I
07 04
I_____I_____I
15 00
I_____I_____I
23 00
I_____I_____I
31 00
I_____I_____I
08 04
I_____I_____I
16 00
I_____I_____I
24 00
I_____I_____I
32 00
I_____I_____I
