Reporting Codes
[320]-[322] Alarm Reporting Codes, Zones 01-34 (All default values are 3A)
[324]-[326] Alarm Restoral Reporting Codes, Zones 01-34
[328] Miscellaneous Alarm Reporting Codes
[329] Priority Alarm and Restoral Reporting Codes
All Reporting Codes are defaulted ‘FF’ unless indicated otherwise.
Section
[320] Zone 01 Zone 02 Zone 03 Zone 04 Zone 05 Zone 06 Zone 07 Zone 08
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
Zone 09 Zone 10 Zone 11 Zone 12 Zone 13 Zone 14 Zone 15 Zone 16
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
[321] Zone 17 Zone 18 Zone 19 Zone 20 Zone 21 Zone 22 Zone 23 Zone 24
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
Zone 25 Zone 26 Zone 27 Zone 28 Zone 29 Zone 30 Zone 31 Zone 32
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
[322] Zone 33 Zone 34
|_3_|_A_| |_3_|_A_|
Section
[324] Zone 01 Zone 02 Zone 03 Zone 04 Zone 05 Zone 06 Zone 07 Zone 08
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
Zone 09 Zone 10 Zone 11 Zone 12 Zone 13 Zone 14 Zone 15 Zone 16
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
[325] Zone 17 Zone 18 Zone 19 Zone 20 Zone 21 Zone 22 Zone 23 Zone 24
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
Zone 25 Zone 26 Zone 27 Zone 28 Zone 29 Zone 30 Zone 31 Zone 32
|_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_| |_3_|_A_|
[326] Zone 33 Zone 34
|_3_|_A_| |_3_|_A_|
|_2_|_1_| Duress Alarm
|_5_|_8_| Opening After Alarm
|_5_|_9_| Recent Closing
|___|___| Future Use
|___|___| Future Use
|_4_|_A_| Cross Zone/Police Code Alarm
|_7_|_8_| Burglary Not Verified
|_A_|_6_| Alarm Cancelled
|_1_|_A_| Keypad [F] Fire Alarm
|_A_|_A_| Keypad [A] Auxiliary Alarm
|_2_|_A_| Keypad [P] Panic Alarm
|___|___| Future Use
|_1_|_A_| Keypad [F] Fire Restoral
|_A_|_A_| Keypad [A] Auxiliary Restoral
|_2_|_A_| Keypad [P] Panic Restoral
|___|___| Future Use
