DSC SCW9045-433 v1.0 User Manual

22
[350] Communicator Format Options
Call Direction Options
[351] Alarm/Restore Communicator Call Directions
[359] Tamper/Restore Communicator Call Directions
[367] Opening/Closing Communicator Call Directions
[345] Maintenance Alarm Reporting Codes [346] Maintenance Restoral Reporting Codes
|_A_|_2_|
Battery Trouble Alarm
|_A_|_2_|
Battery Trouble Restoral
|_A_|_1_|
AC Failure Trouble Alarm
|_A_|_1_|
AC Failure Trouble Restoral
|___|___|
Future Use
|___|___|
Future Use
|_7_|_3_|
Fire Trouble Alarm
|_7_|_3_|
Fire Trouble Restoral
|_1_|_2_|
Auxiliary Power Supply Trouble Alarm
|_1_|_2_|
Auxiliary Power Supply Trouble Restoral
|___|___|
Future Use
|_5_|_1_|
TLM Restoral
|_A_|_A_|
General System Trouble
|_A_|_A_|
General System Trouble Restoral
|___|___|
Future Use
|___|___|
Future Use
[347] Miscellaneous Maintenance Reporting Codes [348] Test Transmission Reporting Codes
|_5_|_4_|
Telephone Number 1 FTC Restoral
|_A_|_7_|
Walk Test End
|_5_|_4_|
Telephone Number 2 FTC Restoral
|_A_|_7_|
Walk Test Begin
|___|___|
Future Use
|___|___|
Future Use
|___|___|
DLS Lead IN
|_A_|_2_|
Periodic Test Transmission
|___|___|
DLS Lead OUT
|_A_|_1_|
System Test
|___|___|
General Zone Fault Alarm
|_8_|_0_|
General Zone Fault Restoral
|_8_|_0_|
Delinquency Reporting Code
|_8_|_4_|
General Zone Low Battery Alarm
|_8_|_4_|
General Zone Low Battery Restoral
|___|___|
Installer Lead Out
|___|___|
Installer Lead In
Default
03 |___|___|
First Telephone Number
03 |___|___|
Second Telephone Number
Third Telephone Number follows format of First Telephone Number
01 20 BPS, 1400 HZ handshake 04 SIA FSK Refer to Appendix B: Communicator Format Options on page 51 for details.
02 20 BPS, 2300 HZ handshake 05 Pager
03 DTMF CONTACT ID 06 Residential Dial
Section
Option 1
First Telephone
Number (Default ON)
Option 2
Second Telephone
Number (Default )
Option 3-8
Not Used
(Default OFF)
[351]
I________I I________I I________I
Section
Option 1
First Telephone
Number (Default ON)
Option 2
Second Telephone
Number (Default )
Option 3-8
Not Used
(Default OFF)
[359]
I________I I________I I________I
Section
Option 1
First Telephone
Number (Default ON)
Option 2
Second Telephone
Number (Default )
Option 3-8
Not Used
(Default OFF)
[367]
I________I I________I I________I
