34
Section [013] First System Options
Section [014] Second System Options
Section [015] Third System Options
Option Description
[1] ON: Hardwired Zone 33 enabled. OFF: PGM1 Output enabled. Program Zone Definition or PGM option in Section [009].
[2] ON: Hardwired Zone 34 enabled. OFF: PGM2 Output enabled. Program Zone Definition or PGM option in Section [009].
[3]-[5] Future Use
[6] ON: Audible Exit Fault Enabled. If a delay zone is not secured correctly and not force-armed, at the end of the exit delay, the
system will go into entry delay and turn ON the bell output.
OFF: Audible Exit Fault Disabled. The keypad will sound the entry delay through the keypad.
[7] ON: Event Buffer Follows Swinger Shutdown. The system will NOT log additional alarms for a zone that has reached the swinger
shutdown threshold. OFF: Event Buffer Logs Past Shutdown. All zone alarms will be logged.
[8] ON: Temporal Three Fire Signal Enabled. Temporal Three Fire Signal is used to annunciate fire alarms (½ second ON, ½ second
OFF, ½ second ON, ½ second OFF, ½ second ON, 1 ½ seconds OFF).
OFF: Standard Pulsed Fire Signal. The system will pulse the bell output (1 second ON, 1 second OFF).
Option Description
[1] ON: Arm/Disarm Bell Squawk Enabled. The system squawks the bell output once when the system is armed, twice when disarmed
and 3 times when disarming with alarms in memory.
OFF: Arm/Disarm Bell Squawk Disabled. The bell output does not activate.
[2] Future Use
[3] ON: RF Jam Logs after 5 Minutes. The system logs an RF Jam trouble condition if the condition is present for 5 minutes. OFF: RF
Jam Logs after 20 Seconds. The system logs the trouble condition after 20 seconds.
[4] ON: Aux Boost Enabled: When the system is in Power Save mode (AC Trouble) Aux+ output voltage is regulated 12VDC.
OFF: Aux Boost Disabled: Aux+ output voltage is not regulated.
[5] Future Use
[6] ON: Audible Exit with Urgency. The system will beep the keypad once every second, and 3 times a second during the last 10
seconds, during exit delay when the system is armed with a user code or armed in the Away mode.
OFF: Silent Exit Delay. The keypad will not beep.
[7] Future Use
[8] ON: Fire Bell is Continuous. The bell
output will not time out if a fire alarm occurs. The User must turn off the bell by entering a
valid user code. OFF: Fire Bell follows Bell Cut-off. The bell output will time out normally.
Option Description
[1] ON: [F] Key Enabled. The keypad [F] fire emergency key will be enabled.
OFF: [F] Key Disabled. The keypad [F] fire emergency key will be disabled.
[2] ON: [P] Key Audible (Bell/Beeps). The keypad [P] panic emergency will generate 3 ack beeps and the bell will activate for the
duration of the BTO or until a code is entered (keypad will display “System in Alarm”).
OFF: [P] Key Silent. The keypad [P] emergency key will generate a silent panic alarm. The bell will not sound and the keypad will
not display “system in alarm”.
[3] ON: Quick Exit Enabled. the Quick Exit feature will be enabled.
OFF: Quick Exit Disabled. the Quick Exit feature will be disabled.
[4] ON: Quick Arming Enabled. The Quick Arming [][0] feature will be enabled.
OFF: Quick Arming Disabled. Quick Arming [][0] feature will be disabled.
If this feature is disabled, a valid user code must be entered after the Stay or Away function buttons are pressed.
[5] ON: Code Required for Bypassing. A valid user code must be entered after pressing [][1] to access the Bypass feature.
OFF: No Code Required. A user code is not required for bypassing.
[6] ON: Master Code Not Changeable. The Master Code (user code 40) can only be changed in Installer Programming.
OFF: Master Code Changeable. The Master Code can be changed using the User Programming [
][5] command.
[7] ON: TLM Enabled. The system supervises the telephone line and displays a trouble if disconnected.
OFF: TLM Disabled. The telephone line is not supervised.
[8] ON: System Tamper Enabled. The panel will monitor the physical tamper switch, if the system is taken off the wall, or the front
housing is removed, a System Tamper Alarm will be generated.
OFF: System Tamper Disabled: The panel will not monitor the physical tamper switch.
