* * 网络化广播系统
网络广播功放 MAG68 系列 网络广播功放 MAG68 系列
3. Example of connection diagram
3.1 Schematic diagram of application of MAG6812 terminal in system
Notes: ① In the above diagram, only the schematic description is given to the connection for the probable
application of MAG68 series power amplifier; please refer to the operation instruction to the networked control
host for the connection of the whole system.
② The above diagram is only used as example; please refer to the schematic diagram of connection for the
specific connection.
③ The connection of MAG68 series power amplifier in the system must be implemented through the
network switch, and the setting of the relevant address is necessary.
Other networks or equipments of
networked address system
Networked broadcasting
power amplifier
Other equipments of networked address system
Control host of networked address system
Networked broadcasting
power amplifier
Networked broadcasting
power amplifier
Networked broadcasting
power amplifier
