3.8.2 Auxiliary Port
Pin
Function
1
RS485 TX+
2
RS485 TX-
3
GND
4
RS485 RX+
5
RS485 RX-
6
12V OUT
7
5V
8
No Connect
9
GND
10
RS232 TX
11
RS232 RX
12
GND
13
No Connect
14
No Connect
15
GND
3.1 Supported USB Dongles
3.1.1 4G Dongle
4G dongles that are currently supported:
 Huawei E3372s-153 (pid 157d)
 Huawei E3372h-153 (pid 1f01)
 Verizon MiFi USB620L 4G (USA)
3.1.2 Wi-Fi Dongle
Wi-Fi dongles that are currently supported:
 TP-LINK AC1300
 TP-LINK AC1200
