HV-500 TECHNICAL DESCRIPTION (BETA VERSION)
3
Revision 1.31
OVERVIEW
Read the manual carefully and thoroughly before using the controller. If you have
any questions, please contact us. info@drivetraininnovation.com
History
07/2016
IGBT and IGBTdriver testing
09/2016
Seventh version final box design
05/2017
Second version prototype hardware testing
11/2017
Using and testing the FOC algorithm for the third version prototype hardware
12/2017
Testing in an automotive environment
02/2018
Final construction
04/2018
Testing in an aerospace environment
05/2018
Adding the resolver and Sin/Cos encoder
07/2018
V1.0 User manual basic specifications
09/2018
Field oriented control with hall sensor improvement
01/2019
V1.1 User interface. Digital I/O and low power wiring diagrams added
Developing field weakening.
03/2019
V1.2 Adding efficiency measurement grap
04/2019
V1.3 High voltage wiring description
Related documents
• DTI Tool user manual
• Motor calibration description
• Analog input setup description
• Can communication description
• Wiring example
