8. Anti-highjack (Only available from Version 1.9 software)
When the tamper alarm function is active and the gate receives a valid trigger but is obstructed
and cannot move or did not move more than 150mm, the alarm or siren will activate.
If the beams are obstructed or blocked when a trigger is received, the gate will open but will
then also sound the alarm.
9. Holiday Lock-out facility (New version PCB’s, this function must be programmed in).
To activate holiday lock-out, (the gate must be in the closed position) press and hold any
pedestrian trigger function for a period of approximately 13 seconds. After approximately
13 seconds the PCB will give one three second beep as acknowledgement that holiday lock-out
is now activated. To de-activate holiday lock-out, repeat the above process. The PCB will
in this instance give five 1 second beeps as acknowledgement de-activate.
(To activate the above, follow the alarm function procedure but utilizing dipswitch 1, 5&6).
List of audio indications and warnings.
One continuous beep - PCB is damage, replace PCB.
One 1.5 second beep - “Party mode” has been activated.
One 2 second beep - Factory defaults have been set.
One 2 second beep - Beams are incorrectly wired or faulty when programming the motor.
or Runtime was aborted for whatever reason.
One 3 second beep - Holiday lockout mode has been activated.
One 3 second beep - Gate triggered when motor is in 3 minute overload lockout.
Two 400 ms beeps - Run time programming (calibrating) has been successful.
Two 1 second beeps - Pedestrian mode was activated.
Two 2 second beeps - No AC power is present, running battery power only.
Three 200ms beeps - Battery power is too low, or
Override function is open or faulty.
Four 100ms beeps - Motor is in holiday lockout.
Four 200ms beeps - Check motor/load fuse (512/25amp or 624/10amp).
- Check motor brushes and armature.
- PCB reader not picking up Magnet on motor.
Five 1 second beeps - Holiday lockout mode has been de-activated.
Twenty 100ms beeps - Motor has stalled or overloaded, then check the following points:
1) Gate pulling force (should not exceed 512/12.5kg or 624/15kg)
2) Load pot is set too low (Turn pot completely clockwise)
3) Battery voltage under load (512/12volt or 624/24volt) (Not connected)
4) Gearbox gearwheel.
List of LED indications.
FOR SAFETY REASONS.
Infra red beams are recommended for
all gate motor installations.
- LED ON when open limit is activated. (gate open).
- LED OFF when close limit is activated. (gate closed).
- LED flashing SLOW (1 sec. on/1 sec. off) (gate is in motion).
- LED flashes 2 long/3 short continuously (gate is stopped midway).
- LED flashes fast (250ms on/250ms off) continuously. (gate in overload).
- LED flashes 3 fast flashes every 1.5 seconds. (battery low, <11/22VDC).
- LED flashes 1 slow/2 fast continuously. (NO 220 VAC power present).
