DTS Raptor - Movement and Shutter Parameters

32
DMX CHANNEL
1
Parameter: PAN msb
DMX CHANNEL
2
Parameter: PAN lsb
DMX CHANNEL
3
Parameter: TILT msb
DMX CHANNEL
4
Parameter: TILT lsb
DMX CHANNEL
5
Parameter: SPEED MOVEMENT
DMX value
Function
000-010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to dmx signal (fast to slow)
248-255
Silent movement
DMX CHANNEL
6
Parameter: PAN FAR(Active only on RAPTOR FPR)
DMX value
Function
000-010
Position mode 540° (standard path)
011-020
Position mode 360° ( 1 turn)
021-030
Position mode 720° ( 2 turns)
031-040
Position mode 1080° ( 3 turns)
041-050
Position mode 1440° ( 4 turns)
051-060
Position mode 1800° ( 5 turns)
061-070
Position mode 2160° ( 6 turns)
071-080
Position mode 2520° ( 7 turns)
081-090
Position mode 2880° ( 8 turns)
091-100
Position mode 3240° ( 9 turns)
101-110
Position mode 3600° (10 turns)
111-120
Position mode 360° smart path
121-182
Forward spin rotation speed from max to min
183-193
Stop
194-255
Reverse spin rotation speed from min to max
