4- TECHNICAL FEATURES

Dimensions

Packaging Dimensions (LxWxH) Unit Dimensions (LxWxH)

420 x 440 x 580 mm 368x288x538mm

Weight: 18,9 Kg Weight: 15,4 Kg

5- ACCESSORIES

As standard

* 1 x Osram Sirius HRI 330W (already installed in the projector) (Code 0505S037)

* 1 x POWERCON male cable connector (Code 0520P014)

* 1 x XLR 5 Pins male cable connector (Code 0508B066)

* 1 x XLR 5 Pins female cable connector (Code 0508B065)

* 2 x Omega clamp with “Fast Lock” connection 1/4 turn

* User’s manual

Optional (on request)

• “C” Clamp G100 black / professional (max. load 200Kg) (Code 0521A015)

• Aliscaf Clamp (max. capacity load 100Kg) (Code 0521A008)

• Safety wire (3mm x 60 cm), ring spring catch, max. capacity load 60Kg (Code

0521A010)
