DTS SCENA LED 120 HQS User Manual

10
8- INPUT / OUTPUT CONNECTIONS
MAINS IN
100-240Vac 50-60 Hz
PowerCON TRUE1
male panel connector
MAINS OUT
100-240Vac 50-60 Hz
MAX 16A
PowerCON TRUE1
female panel connector
Max 20 units @ 230Vac
Max 10 units @ 100Vac
FUSE
T 2A 250V
DISPLAY
PANEL
DMX IN
XLR 5-pole male
panel connector
DMX OUT
XLR 5-pole female
panel connector

DTS SCENA LED 120 HQS Specifications

General

Brand	DTS
Model	SCENA LED 120 HQS
Category	DJ Equipment
Language	English
