DTS SCENA LED 120 HQS User Manual

12
9.1 DMX addresses
SCENA LED 120 HQS can be used in 5 DMX modes:
1. 10 channels (Default)
2. RGBA (4 channels)
3. 6 channels
4. FINE (10 channels)
5. PROM (11 channels)
In order to use the unit in 10 DMX channels mode (Default), set the following
addresses on the mixer:
Projector 1 A001
Projector 2 A011 If you want to select the next projector, just add “10”
Projector 3 A021
….. A….
projector 6 A051
9.2 Selecting the DMX address
1) Press the UP-DOWN key until you reach the required DMX address. The numbers
on the display will start to flash (but the new DMX address hasn't yet been set).
2) Press ENTER to confirm your selection. The numbers on the display will stop
flashing and the projector is now controlled by the new DMX address.
TIPS: if you keep pushed the UP or DOWN keys, the channels are calculated more
quickly and you get a faster selection.
