16
13- DMX PROTOCOL
4 CHANNELS MODE
1 SHUTTER / STROBE
2 DIMMER
3 ZOOM
4 RESET
DMX CHANNEL
1
Parameter: SHUTTER / STROBE
DMX range
Value
Mid Point
DMX
value
Move Range
(degrees)
Mode
Option
Function
000-009
Black-out
010-019
Open
020-029
Black-out
030-119
Strobe (from 3.27 s to 30 ms)
120-149
Pulse up (from 42.6 s to 120 ms)
150-179
Pulse down (from 42.6 s to 120 ms)
180-204
Random strobe
(Dimmer channel active)
205-229
Full independent Random Strobe
(Dimmer channel disabled)
230-255
Open
DMX CHANNEL
2
Parameter: DIMMER
DMX range
Value
Mid Point
DMX
value
Move Range
(degrees)
Mode
Option
Function
000-255
Proportional dimmer
DMX CHANNEL
3
Parameter: ZOOM
DMX range
Value
Mid Point
DMX
value
Move Range
(degrees)
Mode
Option
Function
000-255
Linear ZOOM from Narrow to Wide
(8,2° - 70° PC lens ;
12,8° - 62° FRESNEL lens)
DMX CHANNEL
4
Parameter: RESET
DMX range
Value
Mid Point
DMX
value
Move Range
(degrees)
Mode
Option
Function
000-015
No Effect
016-255
Zoom Motor Reset
(active after 3 sec.)
