DTS XR9 Spot User Manual

18 CHANNELS MODE
1 PAN msb 540°
2 PAN lsb
3 TILT msb 270°
4 TILT lsb
5 SPEED MOVEMENT
6 DIMMER
7 SHUTTER
8 COLOUR 1
9 COLOUR 2
10 GOBO
11 GOBO ROTATION
12 FIXED GOBO
13 IRIS
14 PRISM/PRISM ROTATION
15 FOCUS
16 ZOOM
17 FROST
18 LAMP ON-OFF / RESET
17- DMX PROTOCOL
ARC 1200
XR 9 SPOT
19
DMX CHANNEL 1
Parameter: PAN msb
DMX CHANNEL 2
Parameter: PAN lsb
DMX CHANNEL 3
Parameter: TILT msb
DMX CHANNEL 4
Parameter: TILT lsb
DMX CHANNEL 5
Parameter: SPEED MOVEMENT
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-10 5 Standard
11-25 18 Fast movement
26-127 Vector mode from fast to slow
128-247 Variable time reaction to
DMX signal ( fast to slow)
248-255 251 Slow reaction time to DMX
signal
DMX CHANNEL 6
Parameter: DIMMER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-7 4 Black-out
8-255 Proportional dimmer
