DTS XR9 Spot User Manual

26 CHANNELS MODE (DEFAULT)
1 PAN msb 540°
2 PAN lsb
3 TILT msb 270°
4 TILT lsb
5 SPEED MOVEMENT
6 DIMMER
7 SHUTTER
8 COLOUR 1
9 COLOUR 1 MODE
10 COLOUR 2
11 COLOUR 2 MODE
12 GOBO 1
13 GOBO 1 MODE
14 GOBO 1 ROTATION/INDEX COARSE
15 GOBO 1 INDEX FINE 16 bit
16 GOBO 1 SHAKE
17 GOBO 2
18 GOBO 2 SHAKE
19 IRIS
20 IRIS MACROS
21 PRISM
22 PRISM ROTATION
23 FROST
24 FOCUS
25 ZOOM
26 LAMP ON/OFF - RESET
-
ARC 1200
XR 9 SPOT
25
DMX CHANNEL 1
Parameter: PAN msb
DMX CHANNEL 2
Parameter: PAN lsb
DMX CHANNEL 3
Parameter: TILT msb
DMX CHANNEL 4
Parameter: TILT lsb
DMX CHANNEL 5
Parameter: SPEED MOVEMENT
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-10 5 Standard
11-25 18 Fast movement
26-127 Vector mode from fast to slow
128-247 Variable time reaction to
DMX signal ( fast to slow)
248-255 251 Slow reaction time to DMX
signal
